Westin HDX Bandit Front Bumper

The Westin HDX Bandit Front Bumper combines a heavy duty diamond plate steel bumper with an integrated grille guard built from schedule 40 steel pipe. It carries a built-in 2 inch receiver hitch and two bow shackle mounts rated at 9,500 lbs each.

The bumper bolts on with no drilling or trimming and covers the headlights, grille, hood and front fenders.

What's Included:

• HDX Bandit front bumper with integrated grille guard
• Honeycomb mesh grille panels
• Removable center mesh screen
• Vehicle specific mounting brackets
• Mounting hardware
• Installation instructions

Specifications

• Material: Steel, schedule 40 steel pipe with diamond plate bumper
• Finish: Black powder coat
• Wing Tube Diameter: 2 inch full wraparound wings tied into the bumper
• Headlight Protection Tubes: 1 1/2 inch
• Upright Rubber Strips: 2 3/4 inch wide
• Receiver Hitch: Built-in 2 inch receiver
• Shackle Mounts: Two heavy duty bow shackle mounts rated 9,500 lbs
• Shackle Mount Hole: 15/16 inch diameter
• Grille Protection: Honeycomb mesh with a removable center mesh screen
• Sensor and Camera Provisions: Removable screens for adaptive cruise control and factory camera on late model Ford, parking sensor provisions on late model Chevrolet and Ram
• Lighting: Compatible with factory fog lamps or LED post mount lights
• Mounting: Bolt-on, no drilling or trimming required
