Access LiteRider part 36039 is the 5'4" bed application for the 2017-2027 Honda Ridgeline. The tailgate keeps working normally whether the cover is rolled up or latched shut.
What's Included:
- Pre-rolled LiteRider cover assembly with front bar, bows and rear bar
- Driver and passenger side rails (longer boxes typically get two-piece rails on each side)
- Left and right EZ-Dial tension adjusters with nuts and bolts
- Tight Bite rail clamps
- Front and rear vinyl seals
- Alcohol prep pad for seal installation
- Quick Clip storage straps, attached to the cover
The Element Seal bulkhead gasket, TrailSeal tailgate gasket, sealant for factory box holes, bed liner and any cargo lighting or tools are sold separately and are not in the box.
Features
AutoLatch with slide lock
A cord on the driver side releases the rear bar, and the latch catches automatically when the cover closes. A manual slide lock on the passenger side pushes in to lock and pulls out to release.
EZ-Dial tension adjusters
Turning the dials at the front bar tightens or loosens the fabric with no tools. Setting both sides by the same amount keeps the cover even and drum tight, which helps it shed water and run quieter.
Full-length hook-and-loop sealing
A 1-1/2" slide-in hook strip fastens the fabric edge to each side rail from the cab to the tailgate. Sealing both sides each time you close the cover is part of normal use.
Seals on all four sides
Front and rear vinyl seals and foam along the side rails close off the perimeter, and the front seals add coverage at the bulkhead corners. An Element Seal bulkhead gasket is an available add-on.
1-1/2" raised profile
The cover sits 1-1/2" above the box on black aluminum rails and bars with silver bows. Most long boxes get three bows instead of two.
Quick Clip storage straps
Nylon straps with buckles hold the rolled cover behind the cab, so the whole bed is usable and the rear view stays clear.
Fitment & Compatibility
Fit guidance: Fits the 2017-2027 Honda Ridgeline with the 5'4" bed. With the cover installed, the in-bed trunk lid cannot open fully.
Specifications
-
Brand: Access
-
Series: LiteRider
-
Cover style: Soft roll-up tonneau cover
-
Material: Textured vinyl, reinforced, commercial grade, UV protected
-
Cold-weather flexibility: Vinyl stays flexible to -40°F
-
Color: Black
-
Profile height: 1-1/2" above the box
-
Latch: AutoLatch, driver-side pull cord, latches automatically on closing
-
Secondary lock: 1 manual slide lock, passenger side
-
Tension adjustment: EZ-Dial tension adjusters, tool-free
-
Side sealing: 1-1/2" slide-in hook-and-loop, full length of both rails
-
Weather sealing: Seals on all 4 sides: front and rear vinyl seals, foam on side rails, bulkhead corner seals
-
Element Seal bulkhead gasket: Optional, sold separately
-
Frame: Black aluminum rails and bars, 2 silver bows (most long boxes get 3)
-
Rear bar: Slantback rear design
-
Storage straps: Quick Clip nylon straps with buckles
-
Mounting: Tight Bite clamp-on side rails; some trucks need special hardware (see Installation tab)
-
Warranty: 3-year limited
-
Fits: 2017-2027 Honda Ridgeline
-
Bed: 5'4" bed
-
Part number: 36039
Installation
Type: Clamp-on side rails with Tight Bite clamps; some trucks add special hardware or bolt-on steps · Install: Hand tools and a torque wrench, truck-specific steps on each listing's Installation tab
The cover mounts to side rails fixed along the inside of the box, and the tension adjusters set its fit at the front bar. The Installation tab below lists the steps, torque values and any extra hardware for this truck.
What the instructions for this truck call for:
-
Tools listed: (2) 1/2" Wrenches, 1/8" Allen wrench, Marking pen, Protective eyewear, Scissors, Tape measure or ruler, Ft-lb Torque wrench with 1/2" socket, Spring clamp - optional, (1) 1/2" Wrench, (1) 10 mm Wrench, (1) Protective eyewear, (1) T-30 Torx wrench
-
Torque: the instructions for this truck print no torque value; follow the hardware steps in the sheet.
-
Drilling: the instructions for this truck include no drilling step.
-
Bed liners: Under the rail drop-in bed liner requires minimal modification at front corner of box and back by tailgate. Over the rail drop-in bed liner requires considerable modification.
-
After installing: For trucks with electric tailgates, cover and tailgate should remain closed after installation for at least 24 hours. (electric tailgates only)
Resources
Warranty, Shipping & Returns
Warranty. Agri-Cover backs the LiteRider with a 3-year limited warranty against defects in material and workmanship, counted from the date of receipt or manufacture. It covers repair or replacement of defective parts, not labor, and excludes accident, misuse, improper installation and normal wear. Shipping. The cover arrives pre-rolled with its side rails and mounting hardware packed alongside. Inspect on delivery. Check every component against the parts list and look over the rails and fabric for shipping damage before you start the install.
Returns. Unused items in their original packaging can be returned within 30 days of delivery. If an item arrives damaged, defective or wrong, return shipping is on us. See our Returns & Refunds Policy, or email support@prestigetruck.com with any question.
About Access
Access roll-up covers are designed and built by Agri-Cover, Inc., a Jamestown, North Dakota company whose lineup also spans mud flaps, snow plows, ag tarps, pickup racks, truck toppers and hard covers. The Access Original roll-up has been in the catalog since 1991, and every Access roll-up since has kept the same rail-mounted, hook-and-loop sealed layout.
Access builds seven roll-up lines. The LiteRider is the value choice among the covers that sit 1-1/2" above the box: it carries over the automatic latch, hand-turned tension dials and four-side sealing of the premium lines in a simpler package, with an AutoLatch and single slide lock instead of the AutoLatch II dual system.
Agri-Cover supports the LiteRider with a 3-year limited warranty. The serial number is on a decal under the rear bar by the tailgate; keep it handy for warranty claims and when ordering original replacement parts through Agri-Cover customer service.
