TeraFlex 2"-Stroke SpeedBump & Progressive Bump Stop Kit, Front & Rear, 2.5"-3.5" Lift for 2020-2025 Jeep Gladiator

The 2"-Stroke SpeedBump & Progressive Bump Stop Kit, Front & Rear, 2.5"-3.5" Lift cushions full suspension compression so hard hits stay controlled. A progressive design ramps up resistance near the end of travel instead of stopping the axle abruptly. Part number 1968352 is built for the 2020-2025 Jeep Gladiator.

Not Included:

Lift springs, shocks and the tires are not included, and some setups need extra strike pad spacers sold separately.

Features

Softer bottom-out impacts
TeraFlex bump stops are designed to absorb the energy of hard compression so the axle does not slam into its limit.

Protects the suspension
Stronger bump stop parts help keep the factory stops from deforming and spare the rest of the suspension from harsh contact.

Tunable for your tires
Bump stop reach can be set for the tire size and fender clearance on your Jeep, following the TeraFlex guide.

Made for lifted Jeeps
Each kit is sized for the Jeep and lift range listed, where the factory bump stop setup no longer fits.

On-road and off-road benefit
Controlled compression helps on potholed highways as well as on trail drops and whoops.

Fitment & Compatibility

Specifications

• Brand: TeraFlex
• Series: SpeedBump
• Warranty: Lifetime (TeraFlex bump stops)
• For lift height: 2.5"-3.5"
• Country of origin: Taiwan
• Part number: 1968352
• Estimated install time: 5 hours (TeraFlex estimate)
• Installation: Certified mechanic install recommended by TeraFlex

Installation

Type: Bump stop upgrade  ·  Install: Home garage to shop, some kits cut and drill  ·  Afterward: Check full-compression clearance

Follow the TeraFlex sheet for this kit, set the strike pad spacers for your tires and trim, and confirm clearance at full compression before the first drive. TeraFlex recommends installation by a certified mechanic.

Installs the JT SpeedBump and progressive bump stop kit. The bottom 2" of the jounce tube is cut off, and brake line brackets come off the lower control arms. EcoDiesel models need at least a 0.625" strike pad spacer and the 392 at least 1.25".
Tools named in the guide: Metric sockets and open-end wrenches, Torque wrench, General mechanics tools, Factory service manual, Pipe cutter
Torque: 59 ft-lb, 18mm bolts; 74 ft-lb, 18mm shock bolt and nut, with the Jeep on the ground; 130 ft-lb, front control arm bolts; 12 ft-lb, bump stop mounting hardware; 74.5 in-lb, jounce tube clamp

TeraFlex's installation instructions for this part number are linked under Resources. Read them fully before starting.
