The Forged ST Rear Sway Bar Kit is part of the TeraFlex approach to balancing highway stability with trail articulation on a lifted Jeep. It gives the suspension room to flex when the trail gets uneven. Part number 1774100 fits the 2018-2026 Jeep Wrangler.
Not Included:
Lift components, bump stop spacers, air compressors and installation labor are not included unless the listing says otherwise.
Features
Geometry corrected for lift
Lifting a Jeep changes sway bar angles, and these parts are sized or designed to restore proper sway bar operation at the listed lift heights.
Stability on the highway
Keeping the sway bar working correctly helps control body roll and keeps steering response sharp on pavement.
Flex when you need it
Quick disconnects, trail-rate bars and adjustable arms let the suspension articulate more freely off road.
Durable sealed joints
TeraFlex links use sealed ball sockets or polyurethane joints built for long service with little maintenance.
Engineered around TeraFlex suspension
These parts are designed alongside TeraFlex lift kits and long arm systems, and several listings name the kits they pair with.
Fitment & Compatibility
Fit guidance: Fits: 2018-2026 Jeep Wrangler (JL). Check your trim and factory equipment against the notes before ordering.
Qualifier: JL
Specifications
-
Brand: TeraFlex
-
Position: Rear
-
Country of origin: Taiwan
-
Part number: 1774100
Installation
Type: Sway bars, links and disconnects · Install: Bolt-on; some rear bars need drilling and trimming · Afterward: Cycle the suspension and recheck fasteners
Read the TeraFlex instructions for this part before starting and check any bump stop, wheel backspacing or air supply requirement on the listing. A certified mechanic is recommended. Cycle the suspension afterward to confirm clearance.
Covers the JL rear forged ST sway bar. TeraFlex requires wheels with at least 4-3/4" backspacing and 2" of added rear bump stop, and Sport and Sahara models with the Dana 35 rear axle also need wheel spacers. The bar slides into the crossbeam, spacers set the arm closer to the frame or tire, and the link can go in any of three holes: 10% softer than factory, factory stiffness or 10% stiffer.
Tools named in the guide: Metric sockets and wrenches, Torque wrench, 6mm hex, T-55 Torx
Torque: 25 ft-lb, Bushing bolts (6mm hex); 75 ft-lb, End caps (T-55 Torx); 80 ft-lb, 18mm arm bolts; 45 ft-lb, Link nut, holding the 6mm hex stud; 66 ft-lb, 18mm link bolt, factory hardware reused
TeraFlex's installation instructions for this part number are linked under Resources. Read them fully before starting.
Resources
Warranty, Shipping & Returns
Warranty. TeraFlex backs its products with a limited warranty against defects in materials and workmanship for the original purchaser, on the vehicle the part was first installed on. Sway bars and sway bar links carry a lifetime warranty. If a covered part fails, TeraFlex will repair or replace it or refund the purchase price at its discretion. The warranty does not cover improper installation, missed maintenance, modifications, normal wear, finish wear or racing and competition use, and paint and powder coat finishes are covered for 90 days against defects only. Shipping. The carrier and ship method are set by the size and weight of the cartons when the order is placed; larger kits and axles ship by freight. Inspect on delivery. Inspect the carton and every part as soon as the delivery arrives, note any shipping damage with the carrier, and contact us right away so we can make it right.
Returns. Unused items in their original packaging can be returned within 30 days of delivery. If an item arrives damaged, defective or wrong, return shipping is on us. See our Returns & Refunds Policy, or email support@prestigetruck.com with any question.
