Rigid SR-Series 40" Spot/Drive Behind the Grille Light Kit: single-row LED light bar shown front and back above two long black grille mounting brackets, on white

Rigid SR-Series 40" Spot/Drive Behind the Grille Light Kit for 2024-2027 Chevy Silverado & GMC Sierra 2500/3500 HD

$2,599.99
FREE SHIPPINGNo sales tax Only 1 leftIn stock now  Estimated delivery
Verify fitment with your vehicle
GO
Clear
  • Guaranteed FitmentTeam-confirmed fit or money back
  • No Sales TaxZero sales tax on every order
  • 30-Day Money-Back GuaranteeReturn it within 30 days of delivery for a refund
Prestige Truck customer support

Questions or a custom quote?

Mon to Fri, 9am to 5pm EST

+1 (470) 823-2453 Email Us

Features

  • Vehicle-specific kit: The kit pairs a Rigid light with mounts made for one vehicle.
  • Rigid's install sheet: Rigid's sheet for this kit sets out the mounting and wiring; the summary above notes any cutting or drilling it calls for.
  • One Rigid kit: The light and mounts come as one Rigid kit; the summary above gives Rigid's box list.
  • Rigid LED light included: The title and Specifications name the Rigid light series and beam in this kit.
  • Stainless steel brackets: The brackets are stainless steel with a powder coat Rigid rates for UV resistance.
  • Off-road lighting: Rigid lists the lights in this kit for off-road use unless the SAE compliant row says otherwise.

Description & Fitment

This Rigid 40" behind-the-grille kit carries two SR-Series spot/drive bars on the 2024-2027 Chevrolet Silverado 2500 HD and 3500 HD and GMC Sierra 2500 HD and 3500 HD. It suits HD truck owners who want added off-road light while keeping the factory grille, which is not part of the kit. Spot and driving optics share each bar for reach plus some width, and stainless steel brackets, a relay harness with switch and mounting hardware are included. The install needs no cutting or drilling and takes about 1 hour, not counting wiring.

Fitment & Compatibility

Chevrolet
Years Model Bed Notes
2024-2027 Silverado 2500 HD —
2024-2027 Silverado 3500 HD —
GMC
Years Model Bed Notes
2024-2027 Sierra 2500 HD —
2024-2027 Sierra 3500 HD —

Check your fit: 2024-2027 Chevrolet Silverado 2500 HD and Silverado 3500 HD and 2024-2027 GMC Sierra 2500 HD and Sierra 3500 HD. Ships with two SR-Series bars.

Not for: Model years outside the range above: the body changes between generations, so other years need a different part. Same vehicle, other lights: 46791 (Radiance+ bar, Radiance+ backlit); 46792 (SR-Series bar). Other vehicles in this range use their own part numbers (20643, 46724, 46726, 46727, 46763, 46764, 46765, 46772, 46773, 46774, and more). Road use: Rigid lists no SAE beam for these lights, so they are for off-road use only. The grille is not included.

About Rigid Industries

RIGID
INDUSTRIES.

Rigid Industries started in Gilbert, Arizona in 2006 as a seller of powersports parts. Its engineers decided halogen and HID lamps were holding drivers back and went after a better light, and the company credits that work with its patented Hybrid Optical System and with launching the first LED light bar.

Rigid has since built lighting with OEM partners including Toyota, Ford and Polaris, and it says its lights are made to pass demanding OEM test standards. The range now runs from compact pods and round lights to curved and straight light bars, SAE street-legal lights and vehicle kits. Rigid is part of Clarience Technologies, a group of vehicle lighting, vision and safety brands.

Buying Rigid from Prestige Truck. We are an authorized Rigid dealer, and every Rigid light we sell is new, genuine Rigid product. Rigid's warranty protects the original buyer with proof of purchase and does not extend to lights bought from unauthorized third-party marketplace sellers, so keep your Prestige Truck order receipt with your records.

Frequently Asked Questions

Which vehicles does it fit?

The 2024-2027 Chevrolet Silverado 2500 HD and Silverado 3500 HD and 2024-2027 GMC Sierra 2500 HD and Sierra 3500 HD. Other years use a different Rigid part.

How hard is the install?

Rigid's sheet lists no cutting or drilling, and puts the time at about 1 hour, not counting wiring. Rigid recommends a professional installation; the steps are in the Installation tab.

Is everything in one box?

This is one Rigid kit: the light and the mounts made for this vehicle. The summary at the top of this page gives Rigid's box list for this kit, or says so when Rigid no longer publishes one.

Is this kit street legal?

Only if the SAE compliant row in Specifications says so for this kit. Rigid lists any light without an SAE rating for off-road use only, so keep it switched off on public roads.

What does the warranty cover?

Rigid's warranty against manufacturing defects for the original buyer with proof of purchase. The Warranty row in Specifications gives Rigid's term for this kit, and the Warranty section below has the full terms.

How should I clean the lens?

With mild soap and water or mineral spirits. Rigid's polycarbonate lenses can be damaged by ammonia-based cleaners and by road salt left on them, and that damage isn't covered, so avoid glass cleaners and automatic car washes and rinse salt off with fresh water.

Installation

Install time About 1 hour, not counting wiring
Recommended installationProfessional
What's involvedCooling plate and grille come off, the light bar mounts behind the grille on factory bolts, no drilling
Tools7mm, 10mm and 18mm sockets, ratchet, plastic clip tool, T10 Torx bit

Here's the short version. Follow Rigid's install sheet (below) for the exact positions, wiring and hardware.

  1. Cooling plate off. Check the parts, pull the 10 push pins holding the cooling plate, remove the two T10 bolts on the hood latch extension and lift the plate out.
  2. Top grille bolts. Remove the four 10mm bolts along the top of the grille.
  3. Fascia corners. Take out the T10 screws at the front of each fender liner, ease the flare back to reach the screw at the bumper edge, remove the 7mm corner screw and unclip the fascia panel from its bottom inside corner. Do both sides.
  4. Camera trucks. If the truck has a front camera, disconnect the washer line on the driver side and the camera plug on the passenger side.
  5. Grille off. Pull the grille off its rear clips and rest it on a blanket.
  6. Mounts in. Remove the 10mm and 18mm bolts the sheet marks on the driver side, fit the mount with those same bolts, then repeat on the passenger side.

Stuck on a step? Ask our install experts

Specifications

BrandRigid Industries
Part Number46793
ProductVehicle-specific light kit
Voltage9V-36V DC
BeamSpot/driving
Lumens25,080 raw (Rigid)
Watts259
Amp draw18.5 at 14V
SAE compliantNo (off-road use only)
Weight15 lbs
UPC849774037474

More media

1 video

Warranty, shipping & returns

  • Warranty

    Rigid backs this light with its Limited Lifetime Warranty, which protects the original buyer against manufacturing defects as long as you can show proof of purchase.
    • Rigid sets time limits inside that cover: 5 years when the light is used in commercial, marine or industrial work (heavy-duty settings such as agriculture, mining or manufacturing), and 1 year on powder coating and lenses.
    • If Rigid confirms a defect, it replaces the item, refunds it or issues store credit, at its discretion. Rigid may ask for photos or video before it approves a claim.
    • Not covered: normal maintenance, service or adjustment; opening the light or breaking its water-tight seal, such as taking off the bezel or its screws (unless the light is built for lens swaps); accidents, alteration, misuse, neglect, abuse, vandalism or physical damage; repairs or changes made by anyone other than Rigid; improper installation, including electrical damage from it, or not following Rigid's instructions; use that goes against Rigid's warnings, labels or documentation; use with equipment or parts Rigid didn't make; fire, flood, lightning and other natural events; harsh road hazards, excessive heat and wear beyond normal; and damage caused by the delivering carrier.
    • Lens care: the polycarbonate lens can be damaged by ammonia-based cleaners and, over time, by road salt, and Rigid does not cover either. Clean it with mild soap and water or mineral spirits, rinse salt off with fresh water, and skip automatic car washes, whose soap may contain ammonia.
    • Rigid gives no other express or implied warranty, including merchantability or fitness for a particular purpose, and is not liable for indirect, special, incidental or consequential damages. Rigid also states that some of its lights are built and sold only for off-road driving.
    • Rigid's warranty does not apply to products bought from unauthorized sellers on third-party marketplaces. To make a claim, contact us with your order number and photos of the problem, and we'll take it through Rigid's process with you.
