TeraFlex HD Adjustable Track Bar, Front (3"-4" Lift) for 1997-2006 Jeep Wrangler TJ/LJ, 1984-2001 Cherokee XJ, 1993-1998 Grand Cherokee ZJ & 1986-1992 Comanche MJ
- Guaranteed FitmentTeam-confirmed fit or money back
- No Sales TaxZero sales tax on every order
- 30-Day Money-Back GuaranteeReturn it within 30 days of delivery for a refund
Questions or a custom quote?
Mon to Fri, 9am to 5pm EST
Complete your upgrade
Fits the same truck
Features
- Handles side loads: Built for the lateral forces on the front axle, per TeraFlex.
- Sharper steering: TeraFlex says it improves steering response and handling.
- Re-centers the axle: Adjustable length for proper lateral axle alignment.
- Clears through travel: Cycles through full travel without hitting other parts.
- No cutting or welding: Bolts to factory locations or a relocation bracket.
- System-proven: Used in TeraFlex's 3"-4" Enduro LCG and 8-arm short arm systems.
Description & Fitment
The TeraFlex HD Adjustable Track Bar, Front, is a heavy-duty adjustable replacement for the front track bar on 3"-4" lifted Jeeps across four platforms: the 1997-2006 Wrangler TJ and LJ Unlimited, the 1984-2001 Cherokee XJ, the 1993-1998 Grand Cherokee ZJ and the 1986-1992 Comanche MJ. It stands up to the side loads the front axle sees in turns and off-road, which TeraFlex says sharpens steering response, and its adjustable length re-centers the axle after a lift. It bolts into the factory locations (or a relocation bracket) with no cutting or welding.
Fitment & Compatibility
| Years | Model | Bed | Notes |
|---|---|---|---|
| 1997-2006 | Wrangler | TJ/LJ; 3"-4" lift | |
| 1984-2001 | Cherokee | XJ; 3"-4" lift | |
| 1993-1998 | Grand Cherokee | ZJ; 3"-4" lift | |
| 1986-1992 | Comanche | MJ; 3"-4" lift |
Check your Jeep: TJ/LJ 1997-2006, XJ 1984-2001, ZJ 1993-1998 or MJ 1986-1992 with a 3"-4" lift.
Not for: JK or JL models; TJ High Steer setups (see 4923200).
About TeraFlex
TeraFlex describes itself as a Jeep company at heart, started and staffed by people who drive them. It designs, engineers and builds suspension systems, shocks, axles and performance parts, with the Wrangler and Gladiator at the center of the range.
The company traces its roots to the 1950s and MEPCO (Military Equipment Parts Company), an early supplier of Jeep parts. TeraFlex Manufacturing followed in 1996 to build heavy-duty suspension for the TJ Wrangler, and today's catalog runs from full lift systems and the Falcon shock line to axles, steering and armor.
Authorized TeraFlex dealer. Prestige Truck is an authorized TeraFlex dealer, so what we sell is new and genuine TeraFlex. In TeraFlex's words, its limited warranty extends "only to the consumer who originally purchased the product," so keep your receipt with your build records.
Frequently Asked Questions
Does it fit my XJ Cherokee?
Yes. TeraFlex lists it for the XJ Cherokee, ZJ Grand Cherokee, MJ Comanche and TJ/LJ Wrangler with a 3"-4" lift.
Do I need to weld anything?
No. It bolts into the factory locations or a track bar relocation bracket.
What about lifts over 4" on a TJ?
TeraFlex offers the HD Adjustable Front Track Bar 1743070 for 3.5"-6" TJ/LJ lifts (used with frame bracket 1743031).
What warranty does TeraFlex give?
TeraFlex covers its track bars for life against defects in materials and workmanship, and paint and powder coat finishes for 90 days. Contact us to confirm coverage on your part or to start a claim.
How quickly does it ship?
Shipping is free to the lower 48 states, and most orders arrive within 1-5 business days. We email your tracking number as soon as it ships.
Can you confirm it's the right part before I order?
Yes. Contact us with your VIN or year, model and trim, lift height and steering setup, and we'll check it against TeraFlex's fitment information before it ships.
Installation
Here's the short version. Follow TeraFlex's install sheet (below) for your Jeep's exact steps and torque values.
- Park on level ground with the parking brake set (the job can be done with the vehicle on the ground); this bar needs at least 3" of lift, and from stock it is lengthened about 9/16" for a 3" lift or 3/4" for a 4" lift (p1).
- Unbolt the shocks from the axle (13mm) and free the ABS lines at the frame if equipped.
- Loosen the frame-side nut with a 3/4" wrench without removing it, strike the bracket with a hammer to release the taper, and unbolt the axle end (T50 Torx or 17mm, captured nut) to remove the factory bar.
- Fit the new bar's ball stud in the frame bracket, torque the nut to 60 ft-lbs and fit the new cotter pin, always tightening (never loosening) to line up the pin hole.
- Bolt the axle end in with the supplied hardware (17mm) and torque it to 40 ft-lbs.
- Loosen the adjuster sleeve nuts (15mm), turn the sleeve until the axle is centered under the vehicle, and torque the nuts to 36 ft-lbs.
Stuck on a step?
Specifications
| Brand | TeraFlex |
|---|---|
| Part Number | 1743022 |
| Product Type | Adjustable front track bar |
| Position | Front |
| Lift Range | 3"-4" |
| UPC | 843885023050 |
