Ram 2500 and 3500 Bed Size: 6'4" and 8 ft Beds

How we made this guide: picks and specs come from our catalog and fitment data, owner quotes come from verified reviews and the guide was drafted with AI help, then checked and edited by Trevor Hall.

The Ram 2500 and 3500 come with two bed lengths: a 6 ft 4 in box (76.3 in at the floor, Crew Cab and Mega Cab) and an 8 ft box (98.3 in at the floor, Regular Cab and Crew Cab). Both are 66.4 in wide wall to wall and 51.0 in between the wheel wells, from Ram's spec sheets.

For 2011 to 2026 trucks, the least expensive cover we carry for either bed is the Extang Trifecta e-Series soft folding cover: $339.99 for the 6'4" box and $369.99 for the 8 ft box. See all in our Ram 2500 and 3500 tonneau covers collection.

Ram 2500 and 3500 bed dimensions

These figures come from Ram's 2018 HD catalog and Ram's 2020 Ram 2500 specification sheet. The 2018 catalog is for the 2018 model year, the last of the 2010 to 2018 fourth generation, and the 2020 sheet is for the 2020 model year of the fifth generation (2019 and newer). A cell marked not published is a figure our Ram sources do not give, so we left it out rather than guess.

Ram's 2018 catalog gives the same box figures for the 3500 dually, so the 2500 and 3500 share these two beds. Ram measures the length at the floor with the tailgate closed. Covers are sized along the top of the side rails, so a tape reading there can differ slightly.

2019 and newer: the fifth generation

Ram's 2020 sheet is the newest one we have. It matches the 2018 catalog on width, depth and the 8 ft length, so as far as the published figures go, the two boxes carried over into the new body. Full maker dimensions for 2019 and 2021 to 2026 are not listed here. Ram's 2026 Heavy Duty towing and payload chart still lists the same two beds, 6'4" and 8'. For those years we go by cover fitment, where 6'4" and 8' both appear for 2019 to 2027 trucks.

Owners often miss the cab pairing. Ram's 2020 sheet pairs the 6 ft 4 in box with Crew and Mega Cabs, and the 8 ft box with Regular and Crew Cabs. A Crew Cab can have either box, so check yours.

2010 to 2018: the fourth generation

We could not read the 6 ft 4 in length cleanly from that catalog's table, so the cell shows not published; Ram's 2020 sheet gives 76.3 in for the same box.

Our fitment data splits these trucks into year spans: 2010 only (listed under Dodge), 2011 to 2018 or 2011 to 2026 for covers that carry across generations.

Older Ram and Dodge trucks

Through the 2010 model year the covers we carry are listed under Dodge 2500 and 3500; from 2011 they are listed under Ram. The 2003 to 2009 trucks list 6'4" and 8' beds (two listings use 6'6" for 2003 to 2008). The 1994 to 2002 trucks list 6'6" and 8'. We have no maker dimensions for these, so measure before you order.

Why cover makers list 8' or 8'2" for the same bed

The 6 ft 4 in box is easy, since 76.3 in matches the cover label. The 8 ft box is where labels split: at 98.3 in it is 8 ft 2.3 in, and cover brands round it two ways. Across all years in our fitment data, 145 listings use 8' and 8 use 8'2"; the 8'2" listings are Roll-N-Lock M-Series and M-Series XT parts for 2010 to 2026 trucks.

One label spans several generations, so pick your cover by year, bed length and cab on the part page.

How to check your bed

1. Latch the tailgate, then lay a tape on the top of one side rail at the bulkhead and pull it back to the tailgate's inner face.
2. Repeat on the other rail and keep the smaller figure.
3. Convert to feet: a reading near 76 in is the 6'4" box and one near 98 in is the 8 ft box.

The measuring guide covers the mistakes that throw a reading off. The Ram 1500 has a 6'4" box too, but the 2019 and newer 1500 takes its own covers, so buy by year and model, not by the reading alone; the Ram 1500 bed size guide covers that truck.

Comparing trucks? Our truck bed size chart puts the Ram 2500 and 3500 beds side by side with other pickups.

Covers that fit each bed

In our range every cover is sold as a part for a year span and bed, and prices change with the part, so each block shows the price for the span and bed it names. For the 6'4" box, the Trifecta Signature 2.0 below fits 2011 to 2026 trucks. For the 8 ft box, the BAKFlip MX4 is the least expensive of the three hard covers below, but its 8 ft parts cover only 2003 to 2018 and 2020 to 2023 trucks. The Revolver X4s 8 ft part runs 2011 to 2025 and the RetraxPRO MX 2011 to 2026.

The Revolver X4s rolls onto a spool at the bulkhead and is rated for 400 lb evenly distributed on the closed cover. Some owners report water at the tailgate and a stiffer roll in the cold. One owner of a 2015 Ram 3500 wrote:

“Fits flush without intruding on the space below. Floats comfortably above my fifth wheel without any contact.”

BAK Revolver X4s owner · 5 out of 5 stars

For daily access to a long bed, a retractable holds at any point on its track, and RetraxPRO MX is rated for up to 500 lb evenly distributed. Like every folding, roll-up and retractable cover, it is only as secure as a locked tailgate.

RamBox trucks and dually trucks need a closer look. Most listings say "without RamBox", a few are built for it (notes such as "Built for the RamBox cargo-management system" and "with RamBox; requires removal of utility rails") and some say "except dually" or "Single Rear Wheel", so read the note on your part before you order. See every type of truck bed cover compared or our full tonneau cover range.

What fits in the bed

Plywood comes in 4 by 8 ft sheets that are 48 in across. The boxes measure 51.0 in between the wheel wells, so a sheet rests flat on the floor in either bed. The 8 ft box runs 98.3 in at the floor, enough to close the tailgate on a 96 in sheet. The 6'4" box is 76.3 in, so a full sheet needs the tailgate down. Ram's 2020 sheet gives a 60.4 in tailgate opening, so a 48 in sheet slides in square. Depth is about 20 in, so taller loads stand above the rails, which favors a cover you can fold or roll back.

Frequently asked questions

How long is a Ram 2500 crew cab short bed?

It is the 6 ft 4 in box, which Ram's 2020 sheet gives as 76.3 in at the floor with the tailgate closed. A Crew Cab can also have the 8 ft box, so check which one your truck has.

Are Ram 1500 and 2500 beds the same size?

Partly. Ram's charts for the 2018 Ram 1500 and the 2019 Ram 1500 Classic print the same 6'4" and 8 ft box figures as the 2500 and 3500. The 2019 and newer Ram 1500 has a 6'4" box of the same length but a deeper bed and no 8 ft box, offers a 5'7" option and takes its own covers. Buy by year, model and bed, not by length alone.

Does Ram make a 6-foot bed?

No. On the 2500 and 3500 the shorter box in Ram's sheets is 6 ft 4 in, which cover listings call 6'4". The Ram 1500 adds a 5'7" box.

How wide is a 2026 Ram 2500 bed?

Ram's newest sheet we have, for 2020, gives 66.4 in wall to wall and 51.0 in between the wheel wells. Ram's 2026 Heavy Duty chart still lists the same two beds. We have no separate 2026 figures here, so confirm with a tape measure.

Will a 1500 tonneau cover fit a 2500?

Sometimes. The 2010 to 2026 Ram 2500 and 3500 share the 6'4" bed of the 2009 to 2018 Ram 1500 and the 1500 Classic, so some covers, such as the BAK Revolver X4s, list them as one part. The newest-body Ram 1500 (2019 and later) takes its own covers. Check the listing for your year, model and bed, not the length alone.

Is the Ram 3500 bed the same as the 2500 bed?

Yes for the figures above. Ram's 2018 catalog gives the same 6 ft 4 in and 8 ft box figures for the 3500 dually. Some covers list single rear wheel trucks only or "except dually", so check the fit note.
