For a truck, Jeep or SUV, pick a winch whose rated line pull is at least 1.5 times the gross vehicle weight rating (GVWR). That is Warn's formula for any truck or SUV, and for ATVs and UTVs Warn gives capacity ranges by machine instead. If the sticker in your driver's door jamb reads 7,000 lb (an example number, not any particular model's weight), 7,000 times 1.5 is 10,500 lb, so a 10,000 lb winch falls just short and the 12,000 lb ZEON XD 12-S is the first Warn rating covered here that clears it.
To go the other way, divide the winch rating by 1.5 and round down: a 10,000 lb winch is sized for a vehicle up to about 6,600 lb. Of the Warn winches covered here, that puts trucks and Jeeps on ratings from 10,000 to 16,500 lb. For powersports, Warn's ranges are 2,500 to 3,500 lb for an ATV, 3,500 to 4,500 lb for a two-seat UTV and 4,500 to 5,500 lb for a four-seat UTV, which is where the 3,500 lb VRX 35 and the 4,500 lb AXON 45-S sit. If the parts of a winch are unfamiliar, our explainer on how a truck winch works is the place to begin.
Work out your number in three steps
- Find your weight. For a truck or Jeep, read the GVWR on the driver's door sticker. Warn advises using it, not the curb weight, because the GVWR is the maximum operating weight and the curb weight leaves out people and cargo. For an ATV or UTV, skip the multiplication: Warn sizes powersports winches by machine, 2,500 to 3,500 lb for an ATV, 3,500 to 4,500 lb for a two-seat UTV and 4,500 to 5,500 lb for a four-seat UTV.
- Multiply by 1.5. GVWR is already the maximum loaded weight of the vehicle, so it allows for people and cargo. If a heavy bumper, rack and bigger tires push what you actually run past the GVWR, multiply the higher figure.
- Buy at or above the result. If you land between two sizes, go up; Warn's advice is that you can always go up in capacity. Warn's Basic Guide to Winching adds that you should never exceed the rated capacity of the winch or its rope.
Winch size by vehicle weight
You do not need a winch size calculator, because the rule is one multiplication. This table has already done it for each Warn truck winch covered here; ATVs and UTVs have their own table below. Each row gives the minimum rated pull at the top of its weight band and the smallest model that clears it; larger winches clear it too. The winch collection has other ratings.
| Truck, Jeep or SUV GVWR | Minimum rated pull (weight times 1.5) | Smallest Warn model covered here that clears it |
|---|---|---|
| Up to 6,600 lb | 9,900 lb | All 10,000 lb: ZEON XC 10 from $1,529.99; ZEON XD 10-S from $1,649.99; M8274 from $3,212.99 |
| 6,601 to 8,000 lb | 12,000 lb | ZEON XD 12-S, 12,000 lb, from $1,779.99 |
| 8,001 to 9,300 lb | 13,950 lb | ZEON XD 14-S, 14,000 lb, from $1,899.99 |
| 9,301 to 10,000 lb | 15,000 lb | M15, 15,000 lb, from $2,677.49 |
| 10,001 to 11,000 lb | 16,500 lb | 16.5ti, 16,500 lb, from $2,974.99 |
| Over 11,000 lb | Over 16,500 lb | Above every rating covered here |
10,000 lb, synthetic rope
Warn ZEON XD 10-S Winch, 10,000 lb with 100' Spydura Synthetic Rope (110010)
From $1,649.99 · 100 ft of Spydura synthetic rope at 10,000 lb, sized for a vehicle up to about 6,600 lb. Skip it above that weight.
Why the rated pull drops as rope builds up
The rating on the box is a single-line pull on the first layer of rope on the drum. Warn's guidance is that maximum pulling capacity occurs on that first layer. The more layers of rope on the drum, the lower the pull. Our listings give the pull by drum layer for these three winches:
| Drum layer | ZEON XC 10 | M15 | 16.5ti |
|---|---|---|---|
| Layer 1 (the rating) | 10,000 lb | 15,000 lb | 16,500 lb |
| Layer 2 | 8,246 lb | 12,273 lb | 13,500 lb |
| Layer 3 | 7,015 lb | 10,385 lb | 11,423 lb |
| Layer 4 | 6,104 lb | 9,000 lb | 9,900 lb |
| Layer 5 | 5,402 lb | 7,941 lb | 8,735 lb |
By layer 5 each one is at a little over half its rating. Treat the rating as the best case: the M15 gives 10,385 lb with its rope on layer 3 and 7,941 lb on layer 5. If your number sits close to a size break, go up.
Rope type does not set the rating. The ZEON XC 10 (steel rope), ZEON XD 10-S (synthetic rope) and M8274 (steel rope) are all rated 10,000 lb. Choosing between rope types is a separate decision, compared in synthetic rope vs steel cable.
What a snatch block changes
A snatch block is a rated pulley you buy separately from the winch. Warn's Basic Guide to Winching says a snatch block increases mechanical advantage and pulling power, and recommends a double line through one to reduce the load on the winch. Doubling the line also takes more rope off the drum, leaving fewer layers on it, which the guide says increases pulling power too. Every rating in this guide is a single-line figure, so a block is how you go past that number for one hard pull. The sizing rule still picks the winch for a single line.
Warn's rigging video demonstrates basic techniques and the accessories that go with a winch.
Trucks, Jeeps, ATVs and UTVs
Trucks
A truck's GVWR is on the door sticker, so sizing is a lookup in the table. The 10,000 lb class covered here has three winches: the ZEON XC 10 and M8274 use steel rope and the ZEON XD 10-S uses synthetic. Above that the ratings step up to 12,000, 14,000, 15,000 and 16,500 lb. Once you have your size, our guide to the best truck winches compares the picks by line pull, rope and budget. The truck winches collection has the full list.
12,000 lb
Warn ZEON XD 12-S Winch, 12,000 lb with 80' Spydura Pro Synthetic Rope (110012)
From $1,779.99 · 80 ft of Spydura Pro synthetic rope at 12,000 lb, sized for up to about 8,000 lb. Pick it when your number lands past the 10,000 lb class.
At the top of the range, the M15 and 16.5ti each carry 90 ft of 7/16-inch steel rope. The 16.5ti adds a thermometric indicator to its remote. Check the mount before you buy: the M15 and 16.5ti listings give a 10 by 4.5 inch mounting bolt pattern, and the VRX 35 listing says a vehicle-specific winch mount kit is required and sold separately.
15,000 lb, steel rope
Warn M15 Self-Recovery Winch, 15,000 lb, 90' of 7/16" Steel Rope (47801)
From $2,677.49 · 90 ft of 7/16-inch steel rope at 15,000 lb, sized for up to about 10,000 lb. Skip it if a 12,000 or 14,000 lb winch already clears your number.
Jeeps
Jeeps follow the same rule: GVWR times 1.5. Warn's Jeep guide adds that two-door Jeeps can generally get away with an 8,000 lb winch, while four-door Wrangler Unlimited models are typically best with a 10,000 lb winch. If a steel bumper, tire carrier and bigger tires push your built weight past the GVWR, size from the higher figure. The ZEON XC 10 is the low-profile winch in the 10,000 lb class, with a steel roller fairlead that works feet-down or feet-forward.
Low-profile, 10,000 lb
Warn ZEON XC 10 Winch, 10,000 lb Low-Profile with 80' Steel Rope and Roller Fairlead (110410)
From $1,529.99 · 80 ft of steel rope at 10,000 lb in a low-profile build, sized for up to about 6,600 lb.
ATVs and UTVs
Warn does not use the 1.5 formula for powersports. It gives a capacity range for each kind of machine, shown in the table below. Warn sells the VRX 35 and AXON 45-S in its powersports line, and our listings mark them as ATV and UTV winches, not truck or SUV winches. Rated 3,500 and 4,500 lb, the VRX 35 sits at the top of Warn's ATV range and the AXON 45-S at the top of its two-seat UTV range and the bottom of its four-seat range. The VRX 35 uses steel rope and the AXON 45-S synthetic. See all powersports winches.
| Machine | Warn's capacity range | Warn model covered here |
|---|---|---|
| ATV | 2,500 to 3,500 lb | VRX 35, 3,500 lb (top of the range), from $399.99 |
| Two-seat UTV | 3,500 to 4,500 lb | VRX 35 (3,500 lb) or AXON 45-S (4,500 lb), from $759.99 |
| Four-seat UTV | 4,500 to 5,500 lb | AXON 45-S, 4,500 lb (bottom of the range); other ratings are in the powersports winches collection |
Warn's powersports primer covers the parts of the winch and the recovery accessories for an ATV or side-by-side.
ATV and UTV, 3,500 lb
Warn VRX 35 Powersports Winch, 3,500 lb, 50' 7/32" Steel Rope and Roller Fairlead (101035)
From $399.99 · 50 ft of steel rope at 3,500 lb, the top of Warn's 2,500 to 3,500 lb ATV range.
The VRX 35 draws 192 amps at its rated pull; the ZEON, M15 and 16.5ti winches draw 458 to 507 amps at theirs. One VRX 35 owner who fitted it to an ATV chose a rating above the pull they expect:
“Its a bit overkill for my atv but mainly got it for the low amp draw. I only expect to at max pull about 2000lbs on a single line if that. Otherwise I would be worried about straightening my frame.”
Warn VRX 35 Powersports Winch, 3,500 lb, 50' 7/32" Steel Rope and Roller Fairlead (101035) owner · 5 out of 5 stars
ATV and UTV, 4,500 lb
Warn AXON 45-S Powersports Winch, 4,500 lb, 50' 1/4" Synthetic Rope and Epic Hawse Fairlead (110240)
From $759.99 · 50 ft of synthetic rope at 4,500 lb, the top of Warn's two-seat UTV range and the start of its four-seat range.
Frequently asked questions
What size winch do I need for a truck?
Multiply the GVWR on the driver's door sticker by 1.5 and buy a winch rated at or above the result. A truck with a 7,000 lb GVWR (an example number) needs at least 10,500 lb, so the 12,000 lb ZEON XD 12-S is the first model in the table that clears it. If a bumper, rack and larger tires push the weight you actually run past the GVWR, size from that higher figure.
What size winch do I need for a Jeep?
Use the same rule: the Jeep's GVWR times 1.5. Warn's Jeep guide adds that four-door Wrangler Unlimited models are typically best with a 10,000 lb winch, and two-door Jeeps can generally get away with 8,000 lb. Then pick the smallest model in the table that clears your number.
How much weight can a 10,000 lb winch pull?
Under the 1.5 rule, a 10,000 lb winch is sized for a vehicle up to about 6,600 lb. The 10,000 lb is a single-line pull on the first layer of rope, and it falls as rope builds up on the drum: the ZEON XC 10 is at 5,402 lb on layer 5. Rigged as a double line through a snatch block, the load on the winch drops, which Warn's Basic Guide to Winching gives as the way to make a hard pull.
Will a 5,000 lb winch pull a car?
It is sized for a car of up to about 3,300 lb. Read your car's GVWR from the driver's door sticker, multiply by 1.5 and compare: if the answer is over 5,000 lb, the winch is too small. The smallest truck winch covered here is rated 10,000 lb, and the powersports models stop at 4,500 lb.
Is a 2,500 lb winch enough for an ATV?
For an ATV, yes, at the low end: Warn's ATV range runs from 2,500 to 3,500 lb. For a UTV, no: Warn's ranges start at 3,500 lb for a two-seat UTV and 4,500 lb for a four-seat one. The 3,500 lb VRX 35 covers the top of the ATV range and the bottom of the two-seat UTV range.
How much weight can a 3,000 lb winch pull?
A 3,000 lb winch is a powersports size, and Warn sizes those by machine class rather than by the 1.5 formula: 3,000 lb sits inside Warn's 2,500 to 3,500 lb ATV range. That figure is a single-line rating on the first layer of rope, so it drops as rope builds up on the drum.
Is a bigger winch always better?
No. A bigger winch in the same family spools slower: the ZEON XD no-load line speed falls from 40 ft/min on the 10-S to 31 on the 12-S and 26.1 on the 14-S. Choose the smallest model that clears the rule, and go up a size when your number sits near a break.
What is the best gear ratio for a winch?
There is no single best: a higher ratio trades line speed for pull. In the ZEON XD family the 10-S runs 141:1 at 40 ft/min with no load, the 12-S 176:1 at 31 ft/min and the 14-S 213:1 at 26.1 ft/min, while the M15 and 16.5ti gear down to 315:1.
What size wire does a winch need?
Use the power and ground cables the winch's own manual shows. The ZEON, M15 and 16.5ti winches here draw 458 to 507 amps at rated pull. Our guide to wiring a Warn winch covers the connections from Warn's manuals.
